Pitch: 1.27 mm (0.05 in)
Application: Wire-to-Board
Row Spacing: 1.27 mm (0.05 in)
Housing Color: Black
Contact Gender: Pin (Male)
Current Rating: 1 A
Mounting Angle: Straight
Mounting Style: Through Hole
Number of Rows: 2 Row
Voltage Rating: 125 V
Contact Plating: Gold
Contact Material: Copper Alloy
Housing Material: Thermoplastic
Termination Style: Solder
Mating Post Length: 3.05 mm (0.12 in)
Flammability Rating: UL 94 V-0
Number of Positions: 8 Position
Insulation Resistance: 1 GOhms
Termination Post Length: 2.3 mm (0.091 in)
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
