Width: 7.1 mm (0.28 in)
Height: 11.5 mm (0.453 in)
Length: 19.7 mm (0.776 in)
Industry: Industrial
Compliance: EN/UL 62368-1
Output Power: 1 W
REACH - SVHC: Details
Mounting Style: Through Hole
Isolation Voltage: 6 kV
Number of Outputs: 2 Output
Input Voltage - Max: 26.4 V
Input Voltage - Min: 21.6 V
Input Voltage, Nominal: 24 V
Output Current-Channel 1: 34 mA
Output Current-Channel 2: 34 mA
Output Voltage-Channel 1: 15 V
Output Voltage-Channel 2: - 15 V
Maximum Operating Temperature: + 100 C
Minimum Operating Temperature: - 40 C
