IR sensor: 128 × 96 (12,288 pixels)
Thermal sensitivity/NETD: <70 mK
Field of view (FOV) 53.6°
Minimum focus distance Thermal: 0.1 m (3.94 in)
MSX®: 0.3 m (11.8 in)
Image frequency: 8.7 Hz
Focus: Focus free
Spectral range: 8–14 µm
Screen size: 3.5 in
Digital camera: 5 MP
Digital camera focus: Fixed
Measurement & Analysis
Object temperature range: -20 to 300°C (-4 to 572°F)
Accuracy: 0 to 100°C (32 to 212°F): ±3°C (±5.5°F)
100 to 300°C (212 to 572°F): ±3%
[Ambient temp.: 15 to 35°C (59 to 95°F) and object temp. above 0°C (32°F)]
Measurement functions: Spot
Box with max./min.
Measurement correction: Emissivity; matt/semi-matt/semi-gloss + custom value
Reflected apparent temperature
Atmospheric compensation
Image Storage
Storage media: Internal memory and onboard FLIR Ignite cloud connectivity
Image storage capacity: >5000 images
Image file format: Standard JPEG, 14-bit measurement data included
Communication & Connectivity
USB: USB 2.0, Type-C connector
Bluetooth®: PAN
Image upload: Directly upload images to FLIR Ignite cloud library and services
Additional Information
Battery type Rechargeable: built-in Lithium ion battery
Battery operating time: 4 hours
Charging system: USB-C (1 A)
Charging time: 2 hours
External power operation: 5 V, USB-C
Operating temperature range
-10 to 50°C (14 to 122°F)
Storage temperature range
-40 to 70°C (-40 to 158°F)
Encapsulation Camera housing and lens: IP54 (IEC 60529)
Drop test Designed for 2 m (6.6 ft)
Weight (including battery): 0.19 kg (0.42 lb)
Size (L × W × H): 138 × 84 × 24 mm (5.4 × 3.3 × 0.94 in)
Tripod mounting: (built-in) UNC ¼”-20
