Measurement Ranges and Accuracy
Voltage DC:
99.99 V, ±(0.7% + 2 digits)
999.9 V, ±(0.7% + 2 digits)
Voltage AC:
0.05 V to 99.99 V, ±(1.0% + 5 digits)
999.9 V, 50 Hz to 500 Hz
VFD, ACV: 0.05 V to 99.99 V, 50 Hz to 60 Hz ±(1% + 5 digits)
999.9 V, 50 Hz to 60 Hz ±(1% + 5 digits)
Current DC:
99.99 A, ±(2% + 0.5 A)
999.9 A, ±(2% + 5 digits)
Current AC:
0.10 A to 99.99 A, 50 Hz to 60 Hz ±(2% + 5 digits)
999.9 A, >60 Hz to 400 Hz ±(2.5% + 5 digits)
VFD, ACA 0.10 A to 99.99 A, 50 Hz to 60 Hz ±(2% + 5 digits)
999.9 A, 50 Hz to 60 Hz ±(2% + 5 digits)
Peak Hold ACV:
140.0 V, ±(3.0% + 15 digits)
1400 V, ±(3.0% + 15 digits)
Peak Hold ACA:
140.0 A, ±(3.5% + 15 digits)
1400 A, ±(3.5% + 15 digits)
Frequency:
20.00 Hz to 99.99 Hz, ±(0.5% + 3 digits)
20.0 Hz to 999.9 Hz, ±(0.5% + 3 digits)
0.020 kHz to 9.999 kHz, ±(0.5% + 3 digits)
Total harmonic distortion ACA/ACV: 99.9%, ±(3.0% + 10 digits)
Harmonic distortion: H01–H12 99.9%, ±(5% + 10 digits)
Harmonic distortion: H13–H25 99.9%, ±(10% + 10 digits)
Inrush current ACA:
99.99 A, ±(3% + 0.3 A)
999.9 A, ±(3% + 5 digits)
Watts DC:
9.999 kW (10 V, 5 A min), ±(3% + 0.05 kW)
99.99 kW (10 V, 5 A min), ±(3% + 0.5 kW)
999.9 kW (10 V, 5 A min), ±(3% + 10 digits)
Watts AC:
9.999 kW (10 V, 5 A min), ±(3% + 10 digits)
99.99 kW (10 V, 5 A min), ±(3% + 10 digits)
999.9 kW (10 V, 5 A min), ±(3% + 10 digits)
Power factor: -1.00 to 0.00 to +1.00, ±3° ±1 digit
Resistance:
999.9 Ω, ±(1.0% + 5 digits)
9.999 kΩ, ±(1.0% + 3 digits)
99.99 kΩ, ±(1.0% + 3 digits)
Continuity: 999.9 Ω, ±(1.0% + 5 digits)
Diode: 0.40 V to 0.80 V, ±0.1 V
Capacitance:
3.999 μF, ±(1.9% + 8 digits)
39.99 μF, ±(1.9% + 8 digits)
399.9 μF, ±(1.9% + 8 digits)
3.999 mF, ±(1.9% + 8 digits)
Measuring rate: 3 times per second
Meter Data
Jaw opening: 45 mm (1.77 in)
Bluetooth range: 10 m (32 ft)
Category rating: CAT IV-600 V, CAT III-1000 V
Data recording: Available via METERLiNK App
Drop test: 1.2 m (4 ft)
Communication & Data Storage
Bluetooth range max: 10 m (32 ft)
Power
Auto Power Off: Approximately 30 minutes
Battery Life: 50 hours with alkaline batteries (backlight, work light, and Bluetooth are off)
Power Requirements: 6 × 1.5 V AAA alkaline batteries
General
Dimensions (L x W x H): 276 mm × 101 mm × 50 mm (10.87 in × 3.98 in × 1.97 in)
Jaw Opening: 45 mm (1.77 in)
Weight: Total weight including batteries: 0.65 kg (1.43 lb)
Worklights: Yes
