Display Counts: 40,000
MEASUREMENT & ANALYSIS
AC Current: 10.000 A ± 1.0%
AC Voltage: 1000.0 V ± 0.5%
Capacitance: 40.00 mF ± 0.9%
Category Rating: CAT IV-600 V, CAT III-1000 V
Contact Temperature Type K thermocouple: Yes
Continuity Threshold: 30 Ω ± 0.2%
DC Current: 10.000 A ± 0.2%
DC Voltage: 1000.0 V ± 0.05%
Diode Test: 2 V ± 1.5%
Display Counts: 40,000
Frequency: 100.00 kHz ± 5 digits
Measuring Rate: 10 samples per second
Resistance: 40.00 MΩ ± 0.2%
Temperature Range: -200°C to 1200°C (-328°F to 2192°F) ±1.0%
VFD AC Voltage: 1000.0 V ± 0.5%
COMMUNICATION & DATA STORAGE
Bluetooth range max: 10 m (32 ft)
Data Recording: 10,000 records with METERLiNK
Memory: 99 internal storage locations
POWER
Auto Power Off: Default: 10 minutes
Battery Life: ~100 hours with alkaline batteries (backlight, worklight, and Bluetooth off)
Battery Type: 6 × 1.5 V AAA alkaline batteries
GENERAL
Size (L x W x H): 207.1 mm × 98.1 mm × 60.7 mm (8.15 in × 3.86 in × 2.39 in)
Weight: 601 g (1.33 lb) including batteries
Worklights: Yes
ENVIRONMENTAL & CERTIFICATIONS
Certifications: UL, CE, FCC, UKCA
Drop test: 3 m (9.8 ft)
IP Rating: IP54 dust-protected and splash-resistant
ACCESSORIES
Accessories In the Box: Premium test leads, Type K temperature probe (204°C, 400°F), Warranty card, 6 × AAA Energizer batteries, Quick Start Guide
