Array Format: 640 × 480
Detector Type: Long-Life, Uncooled VOx Microbolometer
Spectral Range: 7.5 μm - 13.5 μm
Effective Resolution: 307,200
Pixel Pitch: 17 µm
Thermal Frame Rate NTSC: 30 Hz
PAL: 25 Hz / 8.3 Hz
Optical Characteristics
FOV: 10°×8°
Focal Length: 65 mm, f/1.25
E-Zoom 4x continuous: E-Zoom
Focus: Athermalized, Focus-Free
Sensitivity:<35 mK @ 25ºC F# 1.0
System Integration
Ethernet: 10/100 Mbps
Control: Input/Output 1× Dry Contact in; 1× Relay Out (rated load 0.09A@ 5VDC)
Network: APIs FLIR SDK, FLIR CGI, ONVIF Profile S
Network
Supported Protocols: IPV4, HTTP, UPnP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, ICMP, IGMP, DHCP, ARP, NFS, SAMBA, HTTPS
Physical
Weight: 9.55lb (4.4kg)
Dimensions (L, W, H): 18.1” × 5.5” × 6.3” (460 × 140 × 160 mm)
Electrical
Input Voltage: 24 VDC (21-30 VDC), 24 VAC (21-30 VAC)
Power Consumption:
24 VAC:15 VA (max w/o heaters), 51 VA (max w/heaters)
24 VDC:10 W (max w/o heaters), 46 W (max w/heaters)
Environmental
IP Rating (Dust & Water Ingress): IP66
Operating Temperature Range: -40°C to 70°C / -40° F to 158°F cold start
Storage Temperature Range: -55° to 85°C / -67° F to 185° F
Humidity: 0-95% relative
Shock: MIL-STD-810F “Transportation”
Vibe: IEC 60068-2-27
De-Icing / Anti-Icing: MIL-STD-810F, Method 521.1; De-Icing of 3/6mm model dependent
Video
Composite Video: NTSC or PAL
Yes: IP & Analog
Analog Video Output Composite: 1Vp-p (PAL or NTSC), 1 × BNC 75Ω
Video Compression: Two independent channels of H.264 & M-JPEG
Streaming Resolution: QVGA to VGA
Thermal AGC Modes Features: Auto AGC / Sharpness (Digital Detail Enhancement (DDE)) / Sensitivity / Brightness / Contrast
Thermal AGC Region of Interest (ROI): Default, Presets and User definable to insure optimal image quality on subjects of interest
Analytics Management: Web-based confguration and management
Analytics Features: Region Entrance/Intrusion Detection, Crossover/Fence Trespassing, Auto/Manual Depth Setup, Human and Vehicle Rules, Hand-off target to PTZ tracking, Tampering, Rule Dependency
Image Uniformity Optimization: Automatic Flat Field Correction (FFC) - Thermal and Temporal Triggers
