FLIR T300341 Thermal Studio Standard (1-year subscription)

File Formats

Image files: JPEGs, radiometric JPEGs

Video files: MP4, CSQ, SEQ

Export formats: PDF, XPS, JPG, ATR, CSV, HTML

Radiometric Analysis

View and edit radiometric images: Yes

Spot, box, line, ellipse/circle: Yes

Delta: Yes

Formulas: Yes, predefined

Measurement alarms: Humidity, insulation

Reporting

With pre-defined templates: Yes

Rapid report: Yes

Custom report templates: Unlimited custom templates

Custom reporting with editor: Yes

Presentation Features

Image presentation modes: MSX®, thermal only, thermal fusion, blending, picture-in-picture, visual only

Image controls: MSX alignment, free rotation, resize, crop

Image annotations: Text, voice

Color distribution: Histogram equalization, signal linear, temperature linear, digital detail enhancement

Custom image overlay: Yes

Streaming and Recording

View non-radiometric video: Yes

Record non-radiometric video: Yes

View radiometric video: Yes

Multi-image Editing/Batch Processing

Scale and units: Yes

Image presentation: Palette, fusion, UltraMax®

Measurements: Spots, clear all

Parameters: Emissivity, distance

Output: Radiometric JPG

Plugin Support (sold separately)

FLIR Si-Series Plugin: Yes (sold separately)

System Compatibility

System requirements: Windows 8 or later / Thermal Studio 1.7 and later versions supports 64-bit only

RAM: Minimum 4 GB

Disk space: Minimum 250 MB
