ACA (jaw): 999.9 A /0.1A / 2 % ± 5 digits
ACA (iFlex): 2500 A /0.1A /3 % ± 5 digits
DCA: 999.9 A /0.1A /2 % ± 5 digits
ACV: 1000 V /0.1V /1.5 % ± 5 digits
DCV: 1000 V /0.1mV /1 % ± 5 digits
R: 60,000 Ω /0.1Ω /1 % ± 5 digits
f: 500 Hz /0.1Hz /0.5 % ± 5 digits
C:1000 µF / 1µF / 1 % ± 4 digits
True-RMS: yes
Continuity: yes
Hold:yes
Backlight: yes
Min/Max/Avg: yes
Inrush: yes
Low pass filter:yes
Include:Soft carrying case,18-inch iFlex probe,2xAA Alkaline batteries,Test Leads, User Manual
| Specifications | |||
| Function | Range | Resolution | Accuracy |
| AC Current via jaw | 999.9 A | 0.1A | 2 % ± 5 digits |
| AC current via iFlex | 2500 A | 0.1A | 3 % ± 5 digits |
| DC current | 999.9 A | 0.1A | 2 % ± 5 digits |
| AC Voltage | 1000 V | 0.1V | 1.5 % ± 5 digits |
| DC Voltage | 1000 V | 0.1mV | 1 % ± 5 digits |
| Resistance | 60,000 Ω | 0.1Ω | 1 % ± 5 digits |
| Frequency | 500 Hz | 0.1Hz | 0.5 % ± 5 digits |
| Capacitance | 1000 µF | 1µF | 1 % ± 4 digits |
| True-RMS | Included | ||
| Continuity | Included | ||
| Hold | Included | ||
| Backlight | Included | ||
| Min/Max/Avg | Included | ||
| Inrush | Included | ||
| Low pass filter | Included | ||
| Wire capacity | 750 MCM or 2-500 MCM | ||
| Safety rating | CAT III 1000 V, CAT IV 600 V | ||
 |
|
