AC Voltage Measurement: 500 V/ ± (0,8% + 3 digit)
Continuity Testing: 20 Ω, 200 Ω, 2000 Ω/± (1,5%+3 digit)
Insulation Resistance Measurement:
+ Test Voltage: 250 V, 500V, 1000V
+ Test Current: 20 Ω, 200 Ω, 2000 Ω/± (1,5%+3 digit)
+ Accuracy: ± (1.5% + 3 digits)
Loop Impedance Measurement: 100 - 500 VAC (50/60 Hz)/ ± (3% + 6 digits) in no Trip mode, ± (2% + 4 digits) in Hi Current mode
PFC, PSC Test: 0 - 25 kA/ Determined by accuracy of loop resistance and mains voltage measurements.
RCD Testing
Tripping Time Test (ΔT)
Tripping Current (ramp): 50% - 110% of RCDs rated current/±5%
Phase Sequence Indication
Size (L x W x H): 10 x 25 x 12.5 cm
Weight 1.3 kg
Batteries: Type AA: 6
|
Specifications |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
AC Voltage Measurement |
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Continuity Testing |
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Insulation Resistance Measurement |
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Loop Impedance Measurement (High Current Mode and Non-Trip Mode) |
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||
