FLUKE FLUKE-408/CNAP Laser Distance Meter (FLUKE-408, 0.2 to 80 m) | EMINKH.COM

FLUKE FLUKE-408/CNAP Laser Distance Meter (FLUKE-408, 0.2 to 80 m)

Name: FLUKE FLUKE-408/CNAP Laser Distance Meter (FLUKE-408, 0.2 to 80 m)
Brand: FLUKE
Availability: InStock

In Stock: 2 Unit

ManufacturerFLUKE(View more products from this manufacturer)

ModelFLUKE-408/CNAP

P/N5301261

OriginChina

Contact

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

Range: 0.2 to 80 m

Accuracy* In favorable condition**: ±(2.0mm+5x10^-5 D)

Accuracy In unfavorable condition***: ±(3.0mm+29x10^-5 D)

Angle accuracy ±(0.3°+0.1°+0.01*A), A is up to ±45° in each quadrant

Angel measurement method: Electronic

Measurement unit: m / ft / in / ft+in

Display: 2.0-inch positive display

Measurements

Single measurement: Yes

Continuous measurement: Yes

Area measurement: Yes

Volume measurement: Yes

Auto Level: Yes

Auto Height: Yes

Pythagoras 2-point: Yes

Pythagoras 3-point: Yes

Add / Substrate Method: Yes

Measurement reference: Front / Tripod hole / Back / Extender

Auto-off: 3 minutes after inactivity

Data Storage: 100 sets

Time-delay measurement: Yes

Auto calibration: Yes

Side button: Yes

Extender: Yes

General

Laser class: Class 2

Laser type: 630 to 670nm, <1mW

Battery life: up to 3500 measurements (single measurement）

Operating temperature: 0 ℃ to 40 ℃

Storage temperature: -10℃ to 60℃

Ingress protection: IP65

Drop test: 1 m

Size: 52 mm × 116mm × 28mm

Weight: 110g

* Temperature for specified accuracy is 25°C

** Favorable conditions: white and diffuse reflection objects (white painted walls) ,low background illumination and moderate temperature

*** Unfavorable conditions: objects with low or high reflectivity, high background illumination or the temperature is at the upper or lower limit of the specific temperature range

Certification

Laser certification: IEC 60825-1: Class 2, 635 nm, <1 mW

CPA, CE

Electrical certification: IEC 61010-1: Pollution Degree 2

EMC： IEC 61326-1: Industrial Electromagnetic Environment CISPR 11: Group 1, Class A

Package

Packaging box: Full telescope

User manual

Vinyl Carrying pouch

Battery 2 AAA NiMH rechargeable cells

Qualification certificate

Lanyard

Charging cable Type-C cable, 0.5m

Datasheet

Manual

Model	Fluke 404E	Fluke 406E	Fluke 405	Fluke 408	Fluke 410
Specifications
Range	0.2 to 40 m	0.2 to 60 m	0.2 to 50 m	0.2 to 80 m	0.2 to 100 m
Accuracy* in favorable condition**	±(2.0mm+5x10-5D)		±(2.0mm+5x10-5D)
Accuracy in unfavorable condition***	±(3.0mm+29x10-5D)		±(3.0mm+29x10-5D)
Angle accuracy	±(0.3°+0.1°+0.01*A), A is up to ±45° in each quadrant
Angel measurement method	Electronic
Measurement unit	m / ft / in / ft+in
Display	1.6 inch, segment alphanumeric display		2.0-inch positive display
* Temperature for specified accuracy: 25°C Favorable conditions: white and diffuse reflection objects (white painted walls) ,low background illumination and moderate temperature * Unfavorable conditions: objects with low or high reflectivity, high background illumination or the temperature is at the upper or lower limit of the specified temperature range
Measurements
Single measurement	●	●	●	●	●
Continuous measurement	●	●	●	●	●
Area measurement	●	●	●	●	●
Volume measurement	●	●	●	●	●
Auto Leveling	●	●	●	●	●
Auto Vertical	●	●	●	●	●
Pythagoras 1	●	●	●	●	●
Pythagoras 2	●	●	●	●	●
Plus-minus method	●	●	●	●	●
Measurement reference	Front / Back		Front / Tripod hole / Back / Extender
Auto-off	3 minutes after inactivity		3 minutes after inactivity
History measurement data	30 sets		100 sets
Time-delay measurement			●	●	●
Auto calibration			●	●	●
Side button			●	●	●
Extender			●	●	●
General
Laser class	Class 2
Laser type	630 to 670nm, <1mW
Battery life	up to 5000 measurements (single measurement)		up to 3500 measurements (single measurement)
Operating temperature	0 C° to 40 C°
Storage temperature	-10 C° to 60 C°
Ingress protection	IP54		IP65
Drop test	1 m		1 m
Size	50 mm × 115mm × 29mm		52 mm × 116mm × 28mm
Weight	100g		110g
Certification
Laser certification	IEC 60825-1: Class 2, 635 nm, <1 mW CPA, CE
Electrical certification	IEC 61010-1: Pollution Degree 2 EMC： IEC 61326-1: Industrial Electromagnetic Environment CISPR 11: Group 1, Class A
Packaging and accessories
Packaging box	Folding box	Folding box	Full telescope	Full telescope	Full telescope
User manual	√	√	√	√	√
Vinyl carrying pouch	√	√	√	√	√
Battery	2 AAA alkaline cells	2 AAA alkaline cells	2 AAA NiMH rechargeable cells	2 AAA NiMH rechargeable cells	2 AAA NiMH rechargeable cells
Qualification certificate	√	√	√	√	√
Lanyard			√	√	√
Charging cable			Type-C cable, 0.5m	Type-C cable, 0.5m	Type-C cable, 0.5m
