Fluid: Uniform liquid through which ultrasonic wave can propagate (water, distilled water, alcohol, etc.)
Pipe inner diameter: 13 mm to 6000 mm (depending on detector)
Fluid temperature: -40°C to +200°C (depending on detector)
Velocity: 0 to ±32 m/s (minimum ±0.3 m/s)
Accuracy: ±1.0% of rate (depending on flow velocity)
Output cycl:e 1 s
Path: 1 path, transit time method
Display: TFT Color LCD with back light
Analog output: 1 point: 4–20 mA DC
Analog input: 2 point: 4–20 mA DC (2 points) or 4–20 mA DC (1 points) and 1–5 V DC (1 points)
Power supply voltage: Built-in battery (12 hours of continuous operation)
Transmitter enclosure: IP64 (no printer version)
Transmitter dimensions: 210 × 120 × 65 mm (no printer version)
Transmitter weight: Approx. 1 kg
SD card: 512 MB (stores 2 years’ worth data), Max. 8 GB
