Basic condition: 23℃±5℃，75%rh below
Rated voltage(V): Model DMG2671: 100V, 250V, 500V,1000V, 2500V, accuracy: ±3%rdg±5dgt
Model DMG2672: 250V,500V, 1000V, 2500V, 5000V, accuracy: ±3%rdg±5dgt
Test voltage (V): Rated voltage×（1±10%）
Resistance range （GΩ）: 0.01MΩ～200GΩ accuracy±3%rdg±5dgt
Resistance resolution: 0.01MΩ
DC voltage range: 0～1000V
DC voltage resolution: 0.1V
AC voltage range: 0～750V
AC voltage resolution: 0.1V
Output short circuit current: ≥1mA(2500V)
Measurement of Absorption ratio and polarization index: Yes
Power supply: 1.5V (LR14) Alkaline battery *6
Back light: Controllable grey screen backlight, suitable for dark places
Display mode: Large LCD display, grey screen backlight
LCD display size: 108mm×65mm
Meter size: 240mm (L)×188mm (W)×85mm (H)
Test wire: Red HV test wire 1m，black 1m，green 1m
Data storage: 500 groups, blinking display “FULL” mean full storage
Data review: Display “READ”
Over range display: Over range function：display “OL”
Warning function: When the measured value exceeds the alarm set value, an alarm prompt will be given
Power consumption: STDBY: 40mA Max (Backlight close)
Turn on with backlight: 43mA Max
measurement：80mA Max (Backlight close)
Weight: 1230g (include battery)
Battery voltage: Insufficient battery voltage, undervoltage indicator display
Auto power-off: hut down after 15 minutes without instrument operation
Insulation resistance: ≥50MΩ (1000V)
Voltage withstand: AC3kV 50Hz 1min
Operating temperature and humidity: -10℃～+50℃＜85%RH
Storage temperature and humidity: -15℃～+55℃＜90%RH
Standard: IEC61010-1、IEC1010-2-31、IEC61557-1,5、 IEC60529(IP54)、pollution class 2、CAT Ⅲ 300V
