Power Supply: AC: 220V/50Hz (optional)
DC: 9V~33V (standard configuration)
Signal Output: RS232 serial output
Two 4～20mA output，the maximum loop load 500Ω(optional) (Dual channels can configure with output freely)
Two relay alarm output (optional) ( The alarm output type can be freely equipped. aw, t, ppm)
LCD Display: Switch water activity(aw), temperature (℃) and water content (ppm) at will
Alarm Line Setting: The alarm value can be set by serial port setting software （aw，t，ppm）(optional)
Probe Type: Several types to be choose according to customers’ needs for the probe length.
Probe Cable Length: 1m（Can be customized for other length）
Working Mode: Support on-line/off-line test
Required Test Temperature: Maximum Pressure: 10 bar
Oil Temperature: -40℃～125℃
Water Activity Collection aw: Test Range: 0～1 aw
Test Resolution: ±0.0003 aw
Test Accuracy: ±0.02 aw @(0～0.8aw)
Repeatability Error: ±0.002 aw
Response Time with Stainless Steel Filter: 10 min
Temperature Collection T: Test Range: -20℃ ～ 80℃
Test Resolution: 0.015℃
Test Accuracy: ±0.5℃ @(0～80℃)
Repeatability Error: ≤ ±0.2℃
Response Time: 30 s
Absolute Water Content AH: Test Range: 0~1000 ppm
IP Grade: IP Grade of Probe: IP67
IP Grade of Shell: IP65
