Leak Measurement
Leak ranges: ±200.0Pa / ±2.000kPa / ±20.00kPa
Accuracy @ 20°C:
10% to 100% range: < ± (1% reading + 1 digit)
0 to 10% range: < ± (0.1% range + 1 digit)
Resolution 4 digit display
Temperature Coefficients:
Zero: Automatic
Span: < ±0.15% per °C
Long Term Drift (span) < ±1% per year
Pressure Measurement
Pressure Ranges:
±99.99mbar / ±200.0mbar / ±999.9mbar
-1bar to +4.000bar / -1bar to +8.000bar / -1bar to +9.999bar / -1bar to +14.00bar / -1bar to + 30.00bar
Accuracy @ 20°C:
10% to 100% range: < ± (1% reading + 1 digit)
0 to 10% range: < ± (0.1% range + 1 digit)
Resolution 4 digit display
Temperature Coefficients:
Zero: < ±0.05% per °C
Span: < ±0.1% per °C
Long Term Drift (span) < ±1% per year
Electrical
Supply Voltage 24VDC ±10% < 1A
Electrical connections
Power: 2 way detachable screw terminal
Outputs: 20 way detachable screw terminal
Inputs: 16 way detachable screw terminal
RS232: 9 pin D plug
RS485: 5 pin detachable screw terminal
LAN: RJ45 connector, 10base-T/100base-TX Ethernet
USB: 1 x USB Type A connector, 1 x USB Type B connector
Control Inputs Up to 24 Opto-isolated, active high or active low. 5VDC to 24VDC into 10K
Control Outputs Up to 32 Active High transistor output (PNP). 12VDC to 45VDC, 120mA (per channel)
Pneumatic
Media Compatibility Clean dry air or non-corrosive gas
Air Supply Pressure Maximum 10bar gauge, Minimum 5bar gauge
Regulator Supply Pressure Maximum 16bar gauge or 35bar for 30bar option
Pneumatic Connections
Air supply: 6mm push-in tube connector
Regulator supply and output: 8mm push-in tube connector
Test/Reference: 1/8” BSPF
Up to 5 programmable pneumatic outputs: 4mm push-in tube connectors
Leak Tightness < 0.2cc/Hour
Construction
Enclosure Steel construction enclosure with paint finish. Suitable for 19” 3U rack mounting.
Dimensions – Rack Case 482 x 133 x 296 mm (W x H x D)
Dimensions – Bench Case 366 x 147 x 296 mm (W x H x D)
Weight 9 kg ± 0.5 kg
