Width: 5.5 mm
Height: 20.8 mm
Length: 16.1 mm
Unit Weight: 6 g
REACH - SVHC: Details
Current Rating: 70 A
Mounting Style: SMD/SMT
Vf - Forward Voltage: 1.4 V
Holding Current Ih Max: 200 mA
Breakover Current IBO Max: 1.4 kA
Gate Trigger Current - Igt: 100 mA
Gate Trigger Voltage - Vgt: 1.5 V
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
Non Repetitive On-State Current: 1.4 kA
Maximum Gate Peak Inverse Voltage: 10 V
Off-State Leakage Current @ VDRM IDRM: 1 mA
Rated Repetitive Off-State Voltage VDRM: 1.2 kV
