Laser diode: red
Self-levelling: horizontal / vertical
Self-levelling range: ± 5°
Accuracy horizontal: ± 0.5 mm / 10 m
Accuracy vertical: ± 1.0 mm / 10 m
Working range without receiver: Ø 40 m
Working area with FR 77-MM: Ø 400 m
Working area with FR 77-MM Tracking: Ø 400 m
Working range tracking function: 110 m
Working range remote control: IR 100 m
Grade: manual
Slope setting manual X-Axis: ± 5° (± 9%)
Slope setting manual Y-Axis: ± 5° (± 9%)
Laser class: 2
Rotating speed rpm: 300, 800
Operating time: 50 h
Power supply: Li-Ion
Dust / water protection: IP 66
Rotating w/o receiver Ø: Ø 40 m
Scanning w/o receiver : 60 m (radius)
90° plumb beam up: yes
Temperature range: -20° to +50°C
TILT-function: yes
Tracking function: yes
Remote control function (on/off): yes
Laserdot mode: yes
VWS function: yes
Scanning: 4 step
Supplied with:
· Receiver FR 77-MM TRACKING with clamp for levelling staff
· Remote control
· Rechargeable batteries
· Charger
· Battery case for alkaline batteries
· Floor mount
· Magnetic target
· Laser glasses
· Carrying case
