Heat Source: Liquefied Petroleum Gas
Density of Heat Flow Rate: ≥40 kW/m²
Counting Range: 0 ~ 100 s
Temperature Measure Range: 20°C ~ 200°C
Sample Dimension: 145 × 145 mm
Calorimeter Diameter: Φ40 mm
Power Supply: 1Ø AC 220V, 50/60 Hz, 1.5 kW
Standards: EN 367, ISO 9151
Accessories
Standard Accessories:
Clamp: 1 pc
Power Line: 1 pc
Optional Accessories:
Pneumatic Sample Cutter GT-C48: Optional
Cutting Die: Optional
Can be digital display flame temperature, measurement temperature, time.
The burner is suitable for combustion of oil gas in the flame nozzle, air holes in Inner-Ring-and-Outer-Ring, calorimeter located inside holes on upper sample holder, which directly touch with sample.
