Load cell capacity: 2000N
Seat load weights: 102kg (225Lb) (weights accumulation)
Back loading force value: 334N (75Lb)/ 445N (100Lb)/ Can be set
Back loading position:
Backrest height > 452mm: 406mm
Backrest height < 452mm: Load on the top of backrest
Back loading force direction: Angle: 90°±10°
Test speed: 10~30 times/min
Test times: 0~999999 times, settable
Force adjustment method:Servo valve + Force sensor
Control: PLC touch screen control
Dimensions (W*D*H): 136*66*140cm
Gap source: Stable gas supply (>6kgf/cm^2)
Power: 1φ, AC 220V, 50/60 HZ 3A
