ELECTRICAL PARAMETERS
Accuracy class : 0.05%, 0.1%
Power supply: One Phase AC 100-265V, frequency 50/60Hz.
AC Voltage output
Range(U1,U2,U3): 57.7V, 100V, 220V, 380V
or 69.3V, 120V, 240V, 480V( optional)
Adjustment range: (0-120)%RG(1)
Adjust fineness: 0.01%RG, 0.1%RG, 1%RG, 10%RG as optional.
Stability: 0.01%/120s
Distortion: 0.3% (Non-capacitive load)
Output load: each phase 30VA
Measuring accuracy: 0.05%RG
AC Current output
Range (I1, I2, I3 ): 200mA, 1A, 5A, 20A, 100A(optional)
Adjustment range: (0-120)%RG
Adjustment fineness: 0.01%RG, 0.1%RG, 1%RG, 10%RG as optional.
Stability: <0.01%/120s
Distortion: ≤0.3% (Non-capacitive load)
Output load: 30VA
Accuracy: 0.05%RG
Power output
Active power output stability: <0.01%RG/120s
Reactive power output stability: <0.02%RG/120s
Active power measuring accuracy: 0.05%RG
Reactive power measuring accuracy: 0.1%RG
Phase Output
Output adjustment range: 0°-359.999°
Output adjustment fineness: 10, 1, 0.1, 0.01 as optional.
Resolution: 0.01°
Accuracy: 0.03°
Power Factor
Adjustment range: -1 ~ 0 ~ 1
Resolution: 10, 1, 0.1, 0.01 as optional.
Measurement accuracy: 0. 0005
Frequency Output
Adjustment range: 40Hz-70Hz
Output adjustment fineness: 5Hz, 1Hz, 0.1Hz, 0.01Hz as optional.
Resolution: 0.001Hz
Accuracy: 0.005Hz
Voltage /Current/Harmonic Setting
Harmonic number: 2-51times
Harmonic content: 0-40%
Harmonic phase: 0-359.99
Harmonic setting accuracy: (10%±0.1%)RD(2)
Power Energy Measurement Error
Active power energy: 0.05%RG
Reactive power energy: 0.1%RG
Power Pulse Output
Power pulse type: active pulse, reactive pulse
Active power pulse output: 5V,10mA
Power Pulse Input
Energy pulse type: support active and reactive pulse, the highest frequency
power pulse input is 180K.
MECHANICAL PARAMETERS
Dimensions (W×D×H) (mm): 495x390x195
Weight (kg): 15
ENVIRONMENTAL CONDITIONS
Ambient temperature: -10°C to +50°C
Relative humidity: 35%-85%
