ELECTRICAL PARAMETERS
Power supply: Single phase AC 220V±10% or 110V±10%, 50/60HzAC
Cooling way: intermittent air cooled
Current output: constant current: 100Amp, 200Amp
Test time: 100Amp: 5-60Sec, 200Amp: 5-30Sec
Test range: 0-20000.0μΩ (100Amp); 0-10000.0μΩ (200Amp)
Accuracy: 0.5%±2bit
Resolution: 0.1μΩ
Max storage volume: 200
LCD: 5.7″black and white LCD display
Communication: RS232 and USB communication interface
Printer: internal installed 58mm wide thermal printer
Standard: DL/T 596-2005, IEC61010-1, IEC61326-1
MECHANICAL PARAMETERS
Dimension (L×W×H) (mm): 415x319x168
Weight (kg): 7.5
ENVIRONMENTAL CONDITIONS
Operating temperature: -10°C ~ 50°C
Storage temperature: -20°C ~ 70°C
Relative humidity: ≤85%RH
