ELECTRICAL PARAMETERS
Power supply: Single phase AC 220V±10% or 110V±10%, 50/60HzAC
Cooling way: intermittent air cooled
Current output: 10mA, 100mA, 1A, 5A, 10A, 20A
Test voltage: DC 28V
Test range: 1mΩ-1Ω (20A); 1mΩ-2Ω (10A); 1mΩ-4Ω (5A); 100mΩ-20Ω (1A); 10Ω-200Ω (100mA); 100Ω-20kΩ (10mA)
Accuracy: 0.2%±2bit
Test voltage: DC 28V
Resolution: 0.1μΩ
Max storage volume: 200 SETS
LCD: 5.7″black and white LCD display
Communication: RS232 and USB communication interface
Printer: internal installed 58mm wide thermal printer
Standard: DL/T 596-1996, IEC61010-1, IEC61326-1, GB6587.1-86
MECHANICAL PARAMETERS
Dimension (L×W×H) (mm): 415x319x168
Weight (kg): 7
ENVIRONMENTAL CONDITIONS
Operating temperature: -20°C ~ 50°C
Storage temperature: -40°C ~ 70°C
Relative humidity: ≤85%RH
