-Sensor:
class B DIN 5032 part 7 or AA according to JIS C 1609-1:2006
class A DIN 5032 part 7 for f1’, u, f3 and f4 or general precision class according to JIS C 1609-1:2006
-Sensor:
Bi-Technology sensor with a photometric broadband detector and a array spectrometer. Integrated aperture for automatic dark signal adjustment.
-Input optics: Diffuser window with 20mm diameter, cosine corrected field of view, f2 ≤ 3%
-Calibration uncertainty: Illuminance +/-2.2%
-Measured Quantity:
PAR - µmol/(m²s)
DLI - Daily Light Integral (time resolved measured with the help of a data logger)
R/FR - Red to Far Red ratio
Esy1, Esy2, Etp1, Etp2 weighting functions
5 different user specific weighting functions
-Microprocessor: 16Bit, 25ns instruction cycle time
-Power Supply: 5VDC, 450mA per USB
-Interface:
USB 2.0 (Type B USB-Port)
Option WiFi: WiFi 2,4 GHz (external antenna, range > 100m)
-Temperature range:
Operation: -10°C to +30°C
Storage: -10°C to +50°C
-Dimensions: 159mm x 85mm x 45mm (Length x Width x Height)
-Weight: 500g
