Spectral responsivity:
CH1: Erythema UV-Aeff (320 - 400) nm
CH2: Erythema UV-BCeff (250 - 320) nm
Typical responsivity:
CH1: UV-A: 1 µA/(W/m²)
CH2: UV-BC: 3.8 nA/(W/m²)
Max. signal current:
CH1: UV-A: 100 µA
CH2: UV-BC: 50 µA
Input optics: 8 mm Ø Diffuser
Measurement ranges:
XD-9509-CH1
min (0.1 pA NEI): 2.50E-08 W/m²
max (100 µA): 2.50E+02 W/m²
XD-9509-CH2
min (0.1 pA NEI): 6.67E-05 W/m²
max (50 µA): 3.33E+04 W/m²
Temperature range: 5 - 40°C
Cable Length: 2m
