Output Voltage: 1–16 VDC
Output Current: 0-5 A
Switching Operation Frequency: 80 kHz to 120 kHz
Efficiency at Max Power: ≥82%
Voltmeter and Ampmeter Display: 3 Digit 7-Segments LED
Voltmeter Accuracy: +1% rdg + 3 digits.
Ammeter Accuracy: +1% rdg + 5 digits
Resolution: 0.1V, 0.01A
Line Input: 100-120 VAC (50-60 Hz) ±10%
Full Load Input Current at 110 VAC: 1.8 A
Cooling System: Natural Convection
Load regulation (10%-90%): ±50 mV
Line regulation (min to max): ±20 mV
Ripple (rms): ±20 mV
Noise (peak to peak): ±100 mV
Load regulation (10%-90%): ±30 mA
Line regulation (min to max): ±10 mA
Output Voltage: 5 V (±5%)
Output Current: 1.2 A Max
Operating Temp/Humidity: max RH of 80% at 31°C, decreasing linearly to 50% at 40°C
Weight: 3.0 lbs (1.4 kg)
Dimensions: 2.8 x 6.0 x 7.9 in (70 x 150 x 200 mm)
