Unit capacity, m3/h (gpm): 16…25 (70… 110)
Kinematic viscosity of product, mm 2/s (St), not more than: 150 (1.5)
Operating temperature, °С (°F), not more than: 150 (302)
Operating pressure, bar (psi), not more than: 10 (145)
Preliminary pressure head on the product supply side, bar (psi), not more than: 0.1 (1.45)
Shaft seal type: packing
Rotor/stator tooling type: nozzle
Replaceable knife kit: optional
Knife axial gap: preset
Minimum knife axial gap, mm (in): 0.5 (2·10-2)
Minimum knife radial gap, mm (in): 0.25 (10-3)
Knife tip speed, m/s (mph), not less than: 45 (100)
Mill shaft and bearing rotation speed, rpm: 7,425
Electric motor shaft rotation speed, rpm: 2,970
Lubrication and cooling of mill shaft bearings: oil bath
Oil volume in bearing assembly, dm3 (gal): 0.2 (0.05)
Mill heating: thermal oil
Required power, kW: 37
Power voltage, V: custom
Dimensions, mm (in), not more than:
· length: 1,060 (42)
· width: 860 (34)
· height: 680 (27)
Weight, not more than, kg (lb): 470 (1036)
