Unit capacity, m3/h (gpm): 2…4 (8.8… 17.6)
Operating temperature, °C (°F), not more than: 150 (302)
Maximum pressure, bar (psi), not more than: 10 (145)
Product operating volume, L: flow
Shaft seal type: packing
Rotor/stator tooling type: nozzle
Replaceable knife kit: optional
Knife axial gap (preset), mm : 0.5…1.5 (2·10-2…6·10-2 )
Knife radial gap mm (in): 0.25 (10-3)
Knife tip speed, m/s (mph), not more than: 45 (100)
Mill shaft and bearing rotation speed, rpm: 6,350
Electric motor shaft rotation speed, rpm: 2,900
Drive power, kW: 11
Power voltage, V: custom
Dimensions, mm (in), not more than:
· length: 900 (35)
· width: 580 (23)
· height: 450 (18)
Weight, kg (lbs), (max): 190 (420)
