Wavelength: 1650nm
Dynamic Range: 20dB
Dead-zone: 1/4m
Fiber Type: SMF
Distance Range: 500m, 1km, 2km, 5km, 10km, 20km, 40km, 80km, 120km
Pulse Width: 3ns/5ns/10ns/30ns/50ns/100ns/275ns/500ns/1us/2us/5us/10us/20us
IOR Setting: 1.000~1.999
Sampling Points: 64000
Sampling Resolution: 0.05m (1km)
Distance Accuracy: ±(1m + Test distance × 3×10⁻⁵ + Sampling resolution) (excluding IOR uncertainty)
Loss Accuracy: 0.1dB
Linearity: ≤0.05dB/dB
Reflectance Accuracy: ±2dB
VFL:
Working wavelength: 650±10nm
Output power: 10mW, CW/1Hz/2Hz
Stable OLS:
Working wavelength: Consistent with OTDR
Output power: >-12dBm, CW/270Hz/1kHz/2kHz
Normal OPM:
Calibrated wavelength: 850/1300/1310/1490/1550/1625/1650nm
Test range: -60~+10dBm
RJ45 Test: RJ45 line sequence test according to TIA568-A or TIA568-B standard
Optical Interface:
OTDR: FC/UPC or SC/UPC
VFL: 2.5mm universal port
OLS: share the OTDR port
OPM: 2.5mm universal port
Electrical Interface:
RJ45 port×2, RJ45 remote module
USB Type-C charging port and data port
Wireless: Bluetooth
Mobilephone APP: Android system
Data Storage: Pluggable 16GB micro SD card
Available Language: English, Spanish, Portuguese, Russian, Hungarian and German (please contact sales for other languages)
Battery: 5000mAh lithium battery
Working Temp: -10℃+50℃
Humidity: 085% (non condensing)
Dimension: 192.9L×93.8W×47Hmm
Weight: 0.57kg
