Imaging and optics
Detector type: VOx, 7.5 to 14μm
Infrared resolution: 120×90@17μm
Super resolution: Support real-time super-resolution reconstruction, Upgrade to 240×180
NETD: 60mK
Frame rate: 25Hz/9Hz
Focal length: 2.28mm
Field of view: 50°×38°
IFOV: 7.46mrad
Min. object distance: 0.1m
D:S: 130:1
Focusing mode: Focus-free
Measurement and analysis
Measurement range Support auto-switching: -20°C to 150°C, 0°C to 550°C
Measurement accuracy ±2°C or ±2%, whichever is greater
Analyzed target Center spot; Three Fixed Areas: Small, Medium, Large (Alternative)
Alarm Full screen temperature threshold alarm (image and flash)
Parameter settings Emissivity, reflected temperature, target distance
Image display
Display screen 2.4" LCD
Image mode IR, VIS, MIF and PIP
Color palettes 6: Iron Red, White Hot, Arctic, Rainbow 2, Hot Iron, Rainbow 1
Image adjustment Level span mode: Automatic, Semi-automatic, Manual
Digital camera 2MP
Functions
Laser: Laser Indication
Recording function: Photo and Video
Storage and transmission
Storage media: Built-in (16 GB)
Image storage: JPG with temp info
Video storage: Supports real-time video streaming, video storage format in Irgd(with temp info)
External interface: USB-C, Tripod socket
WIFI: Yes, it can be connected to the mobile terminal for image and real-time video transmission
Environmental parameters
Working temperature: -15°C to 50°C
IP rating: IP54
Drop: 2m drop test
Certification: CE, FCC, RoHS, KC, EAC, FDA, Anatel, IP54, 2m drop test, Damp heat test, Vibration test, Shock test, Impact test, UN38.3, MSDS
Physical parameters
Hardware: Illuminator
Weight 355g
Software kit PC: ThermoTools; Mobile: Thermography (iOS/Android)
Standard: A device, Wrist strap, Power adapter, Adapter plug, USB-A to USB-C Cable, Data download card, Quick Start Guide, Warranty card, Inspection report
Options: Tripod
