Power: 0~5KW / 0 ~ 7.5kW max.
Current: 0 ~ 200A/ 0 ~ 300A max.
Voltage:
Min.Operatting Voltage: 15V@200A
Protections
Over Power Protection(OPP): 105%
Over Current Protection(OCP): 104%
Over Voltage Protection(OVP): 105%
Over Temp Protection(OTP): 90°C±5°C
Constant Current
Mode
Range: 0~20A/ 0~200A
Resolution: 0.32mA /3.2mA
Constant
Resistance Mode
Range: 360kΩ ~ 6Ω / 6Ω ~ 0.075Ω
Resolution: 2.8μS / 100μΩ
Constant Voltage
Mode
Range: 0 ~ 1200V
Resolution: 20mV
Constant Power
Mode
Range: 0 ~ 500W / 500~ 5kW
Resolution: 8mW / 80mW
Dimension (HxWxD):
177mm x 440mm x 745mm
Weight: 29KG
