Body Material: PPS
Cable Connection: Digital
Cable Length: 10 m (33 ft)
Cable Length: 10 m
Compliance: Hazardous location, Maritime, CE
Electrode Material: gold
Electrode Type: gold
Flow: 3 m (10 ft.) per second, maximum
Mounting: Convertible
Operating Temperature Range: –5 to 70 °C (23 to 158 °F) pHD and ORP
: Before initial pH calibration, calibrate the temperature measurement when the sensor is in water or buffer which is at approximately the same temperature as the pH buffers.
Range: -1500 to +1500 mV ORP
Sensitivity: ± 0.5 mV
Sensor Cable: Integral; 4 conductor cable with one shield and polyurethane jacket; rated to 105 °C (221ºF); 10 m (33 ft.) standard length
Sensor Type: Digital
Temperature Accuracy: ± 0.5 °C (± 0.9 °F)
Temperature Sensor: Sensor Pressure/Temperature Limits; Digital: 6.9 bar
Transmission Distance: 100 m (328 ft.), maximum
Transmission Distance: 1000 m (3280 ft.), maximum when used with a termination box
Warranty: 12 months
Wetted Materials: PEEK or PPS, salt bridge of matching material with PVDF junction, glass process electrode, titanium ground electrode, and FKM/FPM O-ring seals (pH sensor with optional HF-resistant glass process electrode has 316 stainless steel ground electrode, and perfluoroelastomer wetted O-rings; consult factory for other available wetted O-ring materials)
What's included?: Includes: sensor with 33 ft cable and manual
