Max. Test load: 300KN
Load range: 6KN-300KN
Relative error of indicate value of load: ±1%
Max. Ram stroke: 250mm
Max. Tensile space: 800mm(including piston stroke)
Max. Compression space: 700mm(including piston stroke)
Display: Computer control and display
Tensile grips for round specimen: φ6-φ26mm
Tensile grips for flat specimen: 0-15mm
Distance for two columns: 500mm
Upper and lower platen size: 200x200mm
The span of bending: 450mm
Width of bending roller: 140mm
Dia. of bending roller: 30mm
Clamping mode: Hydraulically
Transducer: load cell
Deformation measuring: YYU–10∕50
Dimensions of load frame: 990×600×2435mm
Dimension of controller: 1140×700×930mm
All weight: 2800kg
