Power consumption: 190W
Temperature range: 330 to 450ºC
Temperature stability: ±5ºC at idle temperature
・ Station
Output voltage: AC 24V
Vacuum generator: Vacuum pump, double cylinder type
Vacuum pressure: 80kPa (600mmHg)
Suction flow: 15L/min.
Dimensions: 165(W)×137(H)×244(D)mm
Weight: 4.8kg
・Desoldering Tool
Power consumption: 140W (24V)
Nozzle to ground resistance: < 2Ω
Nozzle to ground potential: < 2 mV
Heating element: Composite heater
Standard nozzle: Φ1.0mm S type (No.N61-05)
Cord length: 1.2m
Total length: 168mm (with Φ1.0mm S type nozzle)
Weight: 190g (with Φ1.0mm S type nozzle)
Packing list: Station, Desoldering tool (FR-4103), Power cord, Iron holder (with cleaning wire), Tool box (Cleaning pin for ø1.0 mm, Cleaning pin for heater, Cleaning drill for ø1.0 mm, Nozzle wrench, Filter [qty 2], Ceramic paper filter [qty 4]), Instruction manual
