Pitch: 2 mm (0.079 in)
REACH - SVHC: Details
Housing Color: Black
Latching Type: Latched
Contact Gender: Socket (Female)
Current Rating: 3 A
Mounting Angle: Straight
Mounting Style: Through Hole
Number of Rows: 2 Row
Voltage Rating: 800 VAC/DC
Contact Plating: Gold
Contact Material: Beryllium Copper
Housing Material: Polyamide (PA)
Termination Style: Solder Pin
Flammability Rating: UL 94 V-0
Number of Positions: 12 Position
Insulation Resistance: 100 MOhms
Termination Post Length: 3 mm (0.118 in)
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
