Specifications
Working voltage range:
AC 50～600V
DC 12～750V
Frequency: 50/60Hz
Dielectric strength: AC2000V for1min
Leakage current: 0.5mA or less
Operation starting voltage [voltage to ground]:
- AC15V±5V; DC6V±3V:
Hold to grounding terminal by bare hands or connect a grounding wire to the ground [company standard].
- AC80V or less: grounding wire is necessary to detect DC.
Function of LED light: O
Operation status indication:
- Light: Continuous light emission in red: Verifiable at 8000Lx
- Sound: Continuous sound: 50dB or more[10cm apart]
Operation temperature range: -10℃～+40℃
Waterproof: equivalent to IPX4
Battery life [with new battery]:
- about 10hr[under continuously operating state without LED]
- about 1.5years[in unused state]
Weight: about 25g[except battery]
Battery: AAA battery [R03/LR03 1.5V] 1pce (Can not use rechargeable battery)
