Measuring Range
Output Current: 100A、80A、50A、30A
Measuring Range: 100A 0~2000µΩ
80A 0~5mΩ
50A 0~10mΩ
30A 0~20mΩ
Technical Index
Accuracy: ±（Reading×0.5%+1µΩ）
Resolution Ratio: 0.1µΩ
Display Digit: Four and a half
Test Power Supply: Constant current limit voltage，about 2V
Input Voltage: Maximum 5V
Measuring Time: Quick、10~60 seconds optional
Testing Times: More than 600 times（full charge, fast measurement mode）
Test Line: Resistance less than 10mΩ
Conditions Of Use and Shape
working Power Supply: Built-in lithium battery or external charger，Charger input 100~240VAC，50HZ/60HZ
Charging Voltage: 12.6V
Charging Current: ≤3A
Charging Time: Abour 3 hrs
Auto Shut Off: 5 minutes automatic shutdown without operation
Instrument Weight: 1.7kg（exclude test lines）
Instrument Dimension: 246mm（L）×156mm（W）×62mm（H）
Environment Temperature: -10℃~50℃
Relative Humidity: ≤90%，no dew
