Output current:
+ Three-phase test: 10A+10A; 5A+5A; 1A+1A; 200mA+200mA; 20mA+20mA
+ Single-phase test: 20A; 10A; 5A; 1A; 200mA; 20mA;
Measurement range:
+ Three-phase test:
10A+10A: 1mΩ～0.6Ω;
5A+5A: 2mΩ～1.2Ω;
1A+1A: 10mΩ～6Ω;
200mA+200mA: 100mΩ～30Ω；
20mA+20mA: 10Ω～200Ω；
+ Single-phase test:
20A: 0.5mΩ～1Ω;
10A: 1mΩ～2Ω;
5A: 2mΩ～4Ω;
1A: 10mΩ～20Ω;
200mA: 100mΩ～100Ω;
20mA: 10Ω～20KΩ;
Accuracy: ±(0.2%+2 digits)
Minimum resolution: 0.1 μΩ
Working temperature: -10～40℃
Ambient humidity: ≤ 80% RH, no condensation
Working power supply: AC220V±10%，50HZ±1HZ
Volume: 428mm* 350mm* 230mm
Net weight: 11.2kg.
