- Barometric pressure:
Display Range: 0-32 in Hg; 0-812 mm Hg
Resolution: 0.01 in Hg; 0.01 mm Hg
- Temperature:
Display Range: 30-900 deg F; -1-480 deg C
Resolution: 0.01 deg F; 0.1 deg C
- Calibration Range:
CFM: 10 - 70
LPM: 280 - 1980
CMM: 0.280 - 1.980
- Meter Connection: 1½” MSPT
- Air Flow: See “Calibration Range” under “Ordering Information”
- Measurement Accuracy:
Flow rate: ± 2% of full scale
Temperature: ± 2 deg F
Barometric pressure: ± 0.2 in Hg @ 25 deg C
- Flow Display: cfm, lpm or cmh (can be programmed for any other units)
- Power Requirements: 110 - 240 VAC
- Overall Dimensions:12” W X 6” D X 11” H
- Weight: 8.5 lbs
- Storage Temperature: -4ºF to 158ºF (-20°C to + 70°C)
- Operating Temperature: 14ºF to 140ºF (-10°C to + 60°C)
- Calibration: Factory calibration is recommended once per year
