Thermal Module
Image sensor: Vanadium Oxide Uncooled Focal Plane Arrays
IR resolution: 640 x 512 (327 680 pixels)
Temperature measurement range: -20°C~650°C (-4°F~1202°F)
Pixel pitch: 17μm
Spectrum range: 8-14μm
NETD: < 35mK (@ 25 °C,F#=1.0)
25mm lens
Thermographic accuracy: ±2℃ / ±2%
Focal length: 25mm
FOV (Field of View): 25°×19°
Minimum focus distance: 0.3 m (0.98 ft)
Focus: Continuous Autofocus/Autofocus/Manual Focus/Laser Assisted Focus
IFOV (Spatial Resolution): 0.68 mrad
Image frequency: 50Hz
Aperture: F1.0
Optical Module
Picture resolution: 2 MP, 5 MP, 8 MP
Video resolution: 640 × 480
Focus: Fixed
FOV: 25°×19°
Display: 800 × 480 Resolution, 4.3’’ LCD Touch Screen
Digital Zoom: 4X
Storage
Storage media: Removable Micro SD Card (64 GB)
Image storage capacity: 60 000 Images
Image file format: JPEG with Measurement Data Included
Video storage capacity: 54 hours
Video file format: MP4
Power System
Power supply: 12 V DC/1.5A, 5V DC/2A (Charging via USB)
Power consumption: 5 W
Battery type: Dismountable and Rechargeable Li-ion Battery
Battery operating time: 4 Hours Continuous Running
General
Menu language: 17 Languages
Working temperature range: -20°C~50°C (4°F~122°F)
Storage temperature range: -20°C~60°C (-4°F~140°F)
Protection level: IP54
Drop Test Height: 2 m (6.56 ft)
Interface: USB Type-C
Weight: Approx.1000 g (2.20 lb)
Dimension: 284.7 mm × 118.3 mm × 127.1 mm (11.21” × 4.66” × 5.00”)
