Measurement specification
Spectral Response: 0.8μm & 1.08μm (Two Color)
Temperature Range: 500°C ~ 1800°C (932°F ~ 3272°F)
Accuracy: ±(0.3%*Tmea + 1)°C or ±(0.3%*Tmea + 1.8)°F, Tmea means "Current measured temperature"
Resolution: 0.1°C / 0.18°F
Repeatability: ±(0.1%*Tmea + 1)°C or ±(0.1%*Tmea + 1.8)°F, Tmea means "Current measured temperature"
Optical Resolution (D): 100:1 (90% energy)
Spot Size: 3mm
Response Time: 1ms
Slope: 0.850 ~ 1.150
Emissivity: 0.100 ~ 1.100
Sighting: Laser, visual display, eyepiece
Signal Processing: Averaging mode, temperature filter mode, peak/valley hold mode
Focus Range: 0.3m ~ 0.6m
Visual
Field of View (FOV): 11° x 8°
Optical Resolution: 2688 * 1944
Data Communication
Analog output:
- Supports proportional output, 16-bit resolution, max load 600Ω
- Interface: 4- 20mA
- Output Types: 4-20mA / 0-20mA / 0-5V / 0-10V
Digital Output: RS485
Alarm Output:
- Supports relay control, dual control methods
- COM output: Optocoupler isolation, delay time less than 2ms
- PNP output: DC24V
Protocols: TCP/IP
General
Power Supply: DC 24V
Power Consumption: Max 10W
Display: 2.4" OLCD screen, resolution 600 * 448
Laser: yes
Protection Level: IP65
Working Temperature Range:
- Without cooling: -20°C to +65°C (-4°F to +149°F)
- With air & water cooling accessories: -20°C to +300°C (-4°F to +572°F)
Storage Temperature Range: -20°C to 70°C (-4°F to +158°F)
Relative Humidity: < 95% non-condensing
Vibration: 1 g, IEC 60068-2-6
Shock: 15 g, IEC 60068-2-27
Dimensions: 87.8 x 92.4 x 229.5mm (3.1 x 3.64 x 9.04 in)
Weight: 1780g (3.92 lb)
