HIOKI 3555 BATTERY HiTESTER
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
| Resistance measurement range | 300 mΩ (Max. display 300.00 mΩ, resolution 100 μΩ) to 30 Ω (Max. display 30.00 Ω, resolution 10 mΩ), 3 ranges Accuracy: ±0.8 % rdg. ±6 dgt. (All ranges) Testing source frequency: 1 kHz ±5 Hz, testing current: 5 mA (300 mΩ range), 500 μA (3 Ω range), 50 μA (30 Ω range) Open-circut Voltage: 5 V peak |
|---|---|
| Voltage measurement range | ± 3 V (Max. display ±3.000 V, resolution: 1 mV) to ± 30 V (Max. display ±30.00 V, resolution: 10 mV), 2 ranges Accuracy: ±0.1 % rdg. ±6 dgt. |
| Absolute max. input voltage | 50 V DC max. (No AC input) |
| Sampling rate | 1.25 times/s (at resistance and voltage measurement combination) |
| Comparator functions | Setting: Upper and lower limit for resistance, and lower limit for voltage, Number of comparator setting: 10 sets Comparator output: Pass (green), Warning (amber), and Fail (red) LEDs, Audible output on warning or Fail |
| Other | Data storage: N/A, Interface: N/A, Temperature measurement: N/A |
| Power supply | LR6 (AA) Alkaline dry battery × 6, Continuous operating time: 18 h |
| Dimensions and mass | 196 mm (7.72 in) W × 130 mm (5.12 in) H × 50 mm (1.97 in) D, 680 g (24.0 oz) (including batteries) |
| Accessories | Pin Type Lead 9461 × 1, Instruction manual × 1, LR6 (AA) alkaline battery × 6 |
