HIOKI 3561 BATTERY HiTESTER

Specification
- Max. applied measurement voltage:
+ ±22 V DC rated input voltage
+ ±70 V DC maximum rated voltage above ground
- Resistance Measurement ranges
+ 300mΩ(max.310mΩ/resolution 10μΩ)~3Ω (Max.3.1Ω/ resolution 100μΩ), 2 range/resolution : ±0.5 % rdg. ±5 dgt
+ Resolution :±0.5 % rdg. ±10 dgt
+ Testing sound Frequency: 1kHz ±0.2Hz
+ Testing current: 10mA (Thang 300mΩ)~1mA (Thang 3Ω)
+ Open-circuit Votalge: 7V
- Voltage Measurement ranges: DC 20 V(resolution 1mV)DC
- Display: 31000 full digits (resistance), 199999 full digits (voltage), LED
- Sampling rate: Four steps:4 ms(Extra-FAST), 12 ms(FAST), 35 ms(Medium), 150 ms(Slow)
- Measurement time: 3ms
- Comparator functions:
+ Setting: Upper and lower limit
+ Output: 3 levels (Hi, In, Lo)
- Analog Output: Measured resistance (displayed value, from 0 to 3.1V DC
- Interface: External I/O, RS-232C, Printer (RS-232C)
- Power supply: 100 to 240 V AC, 50/60 Hz, 30 VA max
- Dimensions, mass: 215 mm (8.46 in) W × 80 mm (3.15 in) H × 295 mm (11.61 in) D, 2.4 kg (84.7 oz)
- Supplied accessories: Power cord × 1
- The warrnty period: 12 month
