- Frequency bandwidth: DC to 120 MHz (-3 dB)
- Rise time: 2.9 ns or shorter
- Noise level: 60 μA rms typical, 75 μA rms max (for 30 MHz band measuring instrument)
- Continuous allowable input: 5 A rms (DC, and sine wave, requires derating at frequency)
- Max. allowable peak input: ±7.5 A peak (non-continuous)
- Amplitude accuracy: Typ.: ±1% rdg. ±1 mV (DC, 45 to 66 Hz sine wave, 0 to 5 A rms)
- Guaranteed: ±3% rdg. ±1 mV (DC, 45 to 66 Hz sine wave, 0 to 5 A rms)
- Output rate: 1 V/A (use with a device having a 1 MΩ input resistance or higher)
- Measurable conductors : Insulated conductor
-Core diameter: φ 5 mm (0.20 in)
- Power supply: ±12 V ±0.5 V, 3.2 VA
- Dimensions and mass Sensor: 155 mm (6.10 in)W × 18 mm (0.71 in)H × 26 mm (1.02 in)D, Terminator: 29 mm (1.14 in)W × 83 mm (3.27 in)H × 40 mm (1.57 in)D mm, Mass: 250 g (8.8 oz), Sensor cable BNC terminal: 1.5 m (4.92 ft), Power cable: 1 m (3.28 ft), Power plug: FFA.0S.304.CLAC37Y / LEMO inc.
- Accessories: Instruction manual ×1, Carrying case ×1
