Pitch: 0.35 mm (0.014 in)
Application: Mobile Phone, Tablet PC, Wearable Device
Stack Height: 0.6 mm
Current Rating: 200 mA, 5 A
Mounting Angle: Straight
Mounting Style: PCB
Number of Rows: 2 Row
Voltage Rating: 30 V
Contact Plating: Gold
Contact Material: Copper Alloy
Housing Material: Liquid Crystal Polymer (LCP)
Termination Style: Solder
Flammability Rating: UL 94 V-0
Number of Positions: 44 Position
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
