Pitch: 1.25 mm (0.049 in)
Wire Gauge: 32 AWG
Housing Color: Beige
Contact Gender: Socket (Female)
Current Rating: 1 A
Housing Gender: Socket
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 1 Row
Voltage Rating: 150 V
Contact Plating: Tin
Contact Material: Phosphor Copper
Housing Material: Polyamide (PA)
Termination Style: Crimp
Flammability Rating: UL 94 V-0
Number of Positions: 8 Position
Insulation Resistance: 500 MOhms
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 35 C
