Pitch: 7.92 mm
Unit Weight: 2.180 g
Housing Color: White
Contact Gender: Socket (Female)
Current Rating: 22 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 2 Row
Voltage Rating: 1 kV
Wire Gauge Max: 10 AWG
Wire Gauge Min: 16 AWG
Contact Plating: Tin
Contact Material: Copper Alloy
Housing Material: Polyamide (PA)
Wire Gauge Range: 16 AWG to 10 AWG
Termination Style: Crimp
Number of Positions: 4 Position
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 55 C
