Pitch: 0.5 mm (0.02 in)
Unit Weight: 363 mg
Stack Height: 1.5 mm
Current Rating: 300 mA
Mounting Angle: Straight
Voltage Rating: 50 VAC
Contact Plating: Gold
Contact Material: Phosphor Bronze
Housing Material: Liquid Crystal Polymer (LCP)
Termination Style: Solder
Flammability Rating: UL 94 V-0
Number of Positions: 40 Position
Insulation Resistance: 500 MOhms
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 35 C
