Pitch: 2 mm (0.079 in)
Application: Wire-to-Board
Row Spacing: 2 mm (0.079 in)
Housing Color: Black
Contact Gender: Pin (Male)
Current Rating: 2 A
Mounting Angle: Right Angle
Mounting Style: Through Hole
Number of Rows: 2 Row
Voltage Rating: 30 V
Contact Plating: Gold
Contact Material: Brass
Housing Material: Polybutylene Terephthalate (PBT)
Termination Style: Solder Pin
Flammability Rating: UL 94 V-0
Number of Positions: 6 Position
Termination Post Length: 3 mm (0.118 in)
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 55 C
