Pitch: 2.2 mm (0.087 in)
IP Rating: IP67
Row Spacing: 2.2 mm (0.087 in)
Unit Weight: 1.830 g
Housing Color: Black
Contact Gender: Pin (Male)
Current Rating: 4 A
Mounting Angle: Straight
Mounting Style: Through Hole
Number of Rows: 3 Row
Voltage Rating: 250 VAC/DC
Contact Plating: Gold
Contact Material: Copper Alloy
Housing Material: Polybutylene Terephthalate (PBT)
Termination Style: Solder Pin
Flammability Rating: UL 94 V-0
Number of Positions: 9 Position
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
