Pitch: 3.96 mm
Unit Weight: 1 g
Housing Color: Black
Contact Gender: Socket (Female)
Current Rating: 14 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 1 Row
Voltage Rating: 630 V
Wire Gauge Max: 16 AWG
Wire Gauge Min: 22 AWG
Contact Plating: Tin
Contact Material: Copper Alloy
Housing Material: Polybutylene Terephthalate (PBT)
Wire Gauge Range: 22 AWG to 16 AWG
Termination Style: Crimp
Number of Positions: 2 Position
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 55 C
