Pitch: 1 mm (0.039 in)
Wire Gauge: 28 AWG
Application: Automotive, Signal, Wire-to-Board
Unit Weight: 100 mg
Housing Color: Black
Current Rating: 2 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 1 Row
Voltage Rating: 60 VAC/DC
Contact Plating: Gold
Contact Material: Copper
Housing Material: Polybutylene Terephthalate (PBT)
Termination Style: Crimp
Flammability Rating: UL 94 V-0
Number of Positions: 2 Position
Insulation Resistance: 500 MOhms
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
